Characterized by contemporary design with clean and geometric lines, with its six different lighting distributions, a choice of two glasses as screens and lumen packages up to 7,500 lumens, Lyra optically meets demands of today’s lighting designers, architects and engineers.
-
Brochure
Add to downloads
Add
-
Add to downloads
Add
-
Technical sheets
Add to downloads
Add
-
IES-LDT
Add to downloads
Add
-
BIM
Add to downloads
Add
-
DWG
Add to downloads
Add
Lyra can be installed on top of posts on connection points with a diameter Ø 60 mm and can be flush mounted on poles with a diameter of Ø 76 mm.
The luminaire is made of die-cast aluminum and sheet steel with a choice of transparent and prismatic glass.
Luminaire main features
- Modular (2X2) refractive lenses in PMMA
- Luminous flux up to 7,500lm
- Optical package consists of 6 lighting distributions
- Color temperature: 3,000K and 4,000K (2,200K and 2,700K on demand)
- Electrical insulation: Class II, Class I
- Enclosure protection: IP66, IK09
- Standard surge protection for differential/common mode 6kV/10kV (CL I, CL II)
- Estimated life: 100,000 h L90B10
